Kettle Fully Automatic Bottle Blowing Machine Plastic Water Pot Making Machine

Kettle Fully Automatic Bottle Blowing Machine Plastic Water Pot Making Machine

  • High Light

    Kettle Fully Automatic Bottle Blowing Machine

    ,

    Plastic Fully Automatic Bottle Blowing Machine

    ,

    Plastic Water Pot Making Machine

  • Condition
    New
  • Video Outgoing-inspection
    Provided
  • Machinery Test Report
    Provided
  • Marketing Type
    New Product 2020
  • Warranty Of Core Components
    1 Year
  • Core Components
    PLC, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump
  • Application
    Bottle
  • Plastic Processed
    PP, HDPE, PC, ABS, PVC, PE, EVA, PA, ABS/PP, PE/PP, HDPE/PP, PETG
  • Year
    2020
  • Voltage
    Customized To Customer Needs
  • Dimension(L*W*H)
    3.2m*2.12m*2.55m
  • Hollow Part Volume
    1-5L
  • Clamping Force (kN)
    110
  • PLC Brand
    MITSUBISHI
  • Screw L/D Ratio
    25
  • Screw Diameter (mm)
    80 Mm
  • Output (kg/h)
    110 Kg/h
  • Automation
    Automatic
  • No. Of Screw Heating Zone
    4
  • Screw Heating Power(kW)
    19 KW
  • Extruder Motor Power(kW)
    30 KW
  • Mold Platen Size(Width)(mm)
    440 Mm
  • Mold Platen Size(Height)(mm)
    420 Mm
  • Air Pressure(MPa)
    0.6 MPa
  • Air Comsumption(m³/min)
    0.4 M³/min
  • Die Head Heating Power(kW)
    10.7 KW
  • Accumulator Capacity(L)
    0 L
  • Power (kW)
    57.8
  • Weight (T)
    8
  • Key Selling Points
    Long Service Life
  • Warranty
    1 Year
  • Applicable Industries
    Energy & Mining, Hotels, Home Use, Machinery Repair Shops, Restaurant, Food & Beverage Factory, Farms
  • Showroom Location
    Egypt, Indonesia, Pakistan, Thailand, Chile, Algeria
  • Rotary Cylinder Brand
    FESTO
  • Station
    Double Station
  • Suitable Bottle
    1-5L
  • Key Words
    Automatic Extrusion Blow Moulding Machine
  • Packing
    Wooden
  • Use
    Hollow Moulding
  • Parison Control
    MOOG
  • Max. Size Of Mold
    440*420
  • Hydraulic Valve
    Yuken
  • Color
    White
  • Port
    Shanghai
  • Place of Origin
    JIANGSU, CHINA
  • Brand Name
    TONGDA
  • Certification
    CE, ISO9001
  • Model Number
    TONGDA HTSII5L
  • Minimum Order Quantity
    1SET
  • Price
    $39,999.00 - $54,999.00/Sets
  • Packaging Details
    PE film, PE bag, Wooden Cases, Wooden Pallet, etc.
  • Delivery Time
    28 working days
  • Payment Terms
    T/T, L/C, D/P, West Union
  • Supply Ability
    800sets/year

Kettle Fully Automatic Bottle Blowing Machine Plastic Water Pot Making Machine

TONGDA HTSII5L Double Color Molding Machine Water Pots Plastic Kettle Making Machine

Product Description

This HTS series machine is our most cost effective series machine. It is suitable for producing HDPE bottles size below 5 liters. If equipped with multi head die-heads, it also suitable for producing small plastic bottles blow molding.

The main parts of this machine are designed and manufactured by ourself.We do the independent R&D and inspection.If you have other special requirements,we can provide customized services for you.



Technical Parameters
MODEL
Units
HTSll-5L
Remarks: we will customize the most suitable machinery according to your requirements
Max. Product volume
L
5

Output of HDPE
kg/h
110

Clamping force
kn
110

Screw diametre
mm
80

Screw heating power
kw
19

Blow pressure
mpa
0.6

Size of machine
m
4.1*2.6*2.7

Kettle Fully Automatic Bottle Blowing Machine Plastic Water Pot Making Machine 0
Kettle Fully Automatic Bottle Blowing Machine Plastic Water Pot Making Machine 1

Product Details

Multi-head die head confituration available for different output requirement, from 1 cavity to 8 cavity, we all can supply.

Kettle Fully Automatic Bottle Blowing Machine Plastic Water Pot Making Machine 2

Parison controller we use MOOG 200 Points or AUTOMATA 300 Points, with extremely sensitive action.

Touch screen we use large size INNOVANCE

Kettle Fully Automatic Bottle Blowing Machine Plastic Water Pot Making Machine 3

After-sales service

Kettle Fully Automatic Bottle Blowing Machine Plastic Water Pot Making Machine 4
Arrange engineer to customer's factory



Company information



1. We have office in Poland, Peru, Chile, Russia, Egypt, Jordan, Thailand, Indonesia, Algeria, Ethiopia, Poland, etc
2. We have benchmark customers in America, Saudi Arabia, Jordan, Qatar, Thailand, Indonesia, etc.
3. Our company has exported over 4000 units machine to more than 120 countries and regions, such as USA, UK, Australia, Greece,Poland.Russia,Belarus,South America, South Africa,Indonesia, Egypt, Syria, Ethiopia.We are not only providing our customers with high quality products, but also provide high quality service Which will be rapidly and timely sent to every customer.

Kettle Fully Automatic Bottle Blowing Machine Plastic Water Pot Making Machine 5Kettle Fully Automatic Bottle Blowing Machine Plastic Water Pot Making Machine 6

FAQ

Advantages of TONGDA tech teams
1. 800 sets of customized requirements per year enable us to have rich experience across multiple industries.
2. Customize equipment models according to customer product characteristics.
3. Project responsibility system, closed-loop team cooperation between the design team and the process team, adjustment of the team, and joint creation of equipment that users are satisfied with.
4. Engineers can study abroad or participate in technical function training of the industry to master the latest information and technical trends of the industry.
5. Undertake a number of large projects, and has a group of senior technical personnel composed of the construction team, can build cable bridge, installation of a complete set of equipment.


Advantages of TONGDA after-sales team
1. Lifetime free service for the machine.
2. Quick response all day long.
3. Set up domestic service team and international service team.
4. Technicians also master the debugging and maintenance of auxiliary equipment.
5. A free 2-day training course will be provided to customers every year.
6. Special processing equipment to produce after-sales accessories to ensure rapid response to user needs.
