Double Station PE Blow Molding Machine Multi Heads Small Daily Chemical Bottles Making

Double Station PE Blow Molding Machine Multi Heads Small Daily Chemical Bottles Making

  • High Light

    PE Blow Molding Machine Multi Heads

    ,

    900*2 PE Blow Molding Machine

    ,

    PE Blow Chemical Bottles Molding Machine

  • Station
    Double Station
  • Dry Cycle
    900*2
  • Weight Of Machine
    6000kg
  • Central Distance Of Bi-head
    130
  • Platen Distance
    138~368
  • Screw Heating Power
    11.2KW
  • Total Power
    39KW
  • Place of Origin
    JIANGSU, CHINA
  • Brand Name
    TONGDA
  • Certification
    CE, ISO9001
  • Model Number
    HTSII-2L
  • Minimum Order Quantity
    1SET
  • Price
    $39,999.00 - $54,999.00/Sets
  • Packaging Details
    PE film, PE bag, Wooden Cases, Wooden Pallet, etc.
  • Delivery Time
    28 working days
  • Payment Terms
    T/T, L/C, D/P, West Union
  • Supply Ability
    800sets/year

Double Station PE Blow Molding Machine Multi Heads Small Daily Chemical Bottles Making

TONGDA HTSII2L Double Station Multi Heads Die Head Small Daily Chemical Bottles Making Machine PE Blow Molding Machine

Product Description

This HTS series machine is our most cost effective series machine. HTSII-2L machine is suitable for producing HDPE bottles size below 2 liters. If equipped with multi heads die-head, it also suitable for small HDPE/PP plastic daily chemical bottles blow molding.

Also can be equipped with view strip line on the die head, and multi layer configuration is also available.

The main parts of this machine are designed and manufactured by ourself.We do the independent R&D and inspection.If you have other special requirements,we can provide customized services for you.




Technical Parameters
MODEL
Units
HTSll-2L
Remarks: we will customize the most suitable machinery according to your requirements
Max. Product volume
L
2

Output of HDPE
kg/h
60

Clamping force
kn
44

Screw diametre
mm
60

Screw heating power
kw
11.2

Blow pressure
mpa
0.6

Size of machine
m
4.1*2.6*2.7

Double Station PE Blow Molding Machine Multi Heads Small Daily Chemical Bottles Making 0



Product Details

Double Station PE Blow Molding Machine Multi Heads Small Daily Chemical Bottles Making 1

Air valve enlarged to ensure better shaping.

Multi-layer, durable tubes are used



Plasticizing system can be designed for multi-layers, 1-4 layers are definitely available, and have high degree customization space.

Honeycomb ventilation holes to ensure better heat dissipation performance.



Stable and efficient clamping system

Adjustable rotary type blow pin unit, suitable for oblique bottles






After-sales service

Double Station PE Blow Molding Machine Multi Heads Small Daily Chemical Bottles Making 2
Arrange engineer to customer's factory



FAQ


Q: how big is your company?
A: our company has 270 employees and A building area of 53,330 square meters. We own land and factories.The company has a registered capital of us $2 million and a long-term business license since 1998.

Q: how long is the warranty on your equipment?
A: we offer A one-year free warranty and A lifetime after-sales service.
