Double Station Extrusion Blow Mold Machine

Double Station Extrusion Blow Mold Machine

  • High Light

    Double Station Extrusion Blow Mold Machine

    ,

    5L Extrusion Blow Mold Machine

    ,

    10L Plastic Jerry Can Making Machine

  • Station
    Double
  • Screw Diametre
    100mm
  • Output Of HDPE
    180 Kg/hour
  • Clamping Force
    158KN
  • Mold Moving Stroke
    600mm
  • Max.Size Of Mold
    590*500mm
  • Air Consumption
    0.8 M3/min
  • Water Consumption
    60 L/min
  • Place of Origin
    CHINA
  • Brand Name
    TONGDA
  • Certification
    CE, ISO9001
  • Model Number
    HSII-12L
  • Minimum Order Quantity
    1 set
  • Price
    USD 92,500~99,999 per set
  • Packaging Details
    Wooden case, PE film, Wooden pallet
  • Delivery Time
    28 working days
  • Payment Terms
    L/C, T/T, D/P, Western Union
  • Supply Ability
    800 sets per year

Double Station Extrusion Blow Mold Machine

TONGDA HSII-12L Double Station 5L 10L Stackable Jerry Can Production Blowing Machine Extrusion Blow Molding Machine



Product Description



This is our high level series extrusion blow molding machine. With hydraulic servo system. The clamping unit is elbow style and the clamping force is more uniform. It is high speed, energy-saving and stable running.
This machine is suitable for production jerry cans, daily chemical bottles. If equipped with multi die-heads, then is suitable for making small plastic bottles.
The main parts of this machine are designed and manufactured by ourself. We do the independent R&D and inspection. If you have other special requirements, we can provide customized services for you.
Double Station Extrusion Blow Mold Machine 0



Double Station Extrusion Blow Mold Machine 1



Technical Parameters



MODEL Units HSII-12 Remarks: we will customize the most suitable machinery according to your requirements
Max. Product volume L 12
Output of HDPE kg/h 180
Clamping force kn 158
Screw diametre mm 100
Screw heating power kw 21
Blow pressure mpa 0.6
Size of machine m 4.9*3.1*3.2


Product Details



Double Station Extrusion Blow Mold Machine 2



Our Advantages


Double Station Extrusion Blow Mold Machine 3

Double Station Extrusion Blow Mold Machine 4

Double Station Extrusion Blow Mold Machine 5

Double Station Extrusion Blow Mold Machine 6





Service Marketing Network

TONGDA HSII-5L Servo System High Speed Double Station Plastic Bottle Making Extrusion Blowing Machine 7

1.Over four thousand Tongda machines have been serving customers all over the world.

2.The company has service outlets in Russia, Egypt, Jordan, Thailand, Chile, Indonesia and Algeria.

3.our company has exported over 4000 units machine to more than 89 countries and regions, such as USA, UK, Australia, Greece,Poland.Russia,Belarus,South America, South Africa,Indonesia, Egypt, Syria, Ethiopia.We are not only providing our customers with high quality products, but also provide high quality service Which will be rapidly and timely sent to every customer.



TONGDA HSII-5L Servo System High Speed Double Station Plastic Bottle Making Extrusion Blowing Machine 8
Our Machinery has been keeping good cooperative relationship with customers since our establishing.
The satisfaction of our customers are the pursuit of every member of Tongda,The only way we service in the competitive market is to help our customers to full fill their requirement.



FAQ



TONGDA sales consultant
1. We can provide comprehensive and professional Suggestions on equipment selection.
2. Energy consumption calculation and investment income analysis can be provided.
3. Provide tailor-made CAD drawings of workshop layout and product optimization Suggestions.
4. Extrusion plastic bottle blow molding machine has remote maintenance function

Advantages of TONGDA tech teams
1. 600 sets of customized requirements per year enable us to have rich experience across multiple industries.
2. Customize equipment models according to customer product characteristics.
3. Project responsibility system, closed-loop team cooperation between the design team and the process team, adjustment of the team, and joint creation of equipment that users are satisfied with.
4. Engineers can study abroad or participate in technical function training of the industry to master the latest information and technical trends of the industry.
5. Undertake a number of large projects, and has a group of senior technical personnel composed of the construction team, can build cable bridge, installation of a complete set of equipment.

Advantages of TONGDA after-sales team
1. Lifetime free service for the machine.
2. Quick response all day long.
3. Set up domestic service team and international service team.
4. Technicians also master the debugging and maintenance of auxiliary equipment.
5. A free 2-day training course will be provided to customers every year.
6. Special processing equipment to produce after-sales accessories to ensure rapid response to user needs.

Q: how big is your company?
A: our company has 400 employees and A building area of 100,000 square meters. We own land and factories.The company has a registered capital of us $2 million and a long-term business license since 1998.

Q: how long is the warranty on your equipment?
A: we offer A one-year free warranty and A lifetime after-sales service.
